FML 5 ... 100 kvar STANDARD PRISMATIC CAPACITOR
FML系列 5-100kvar 标准棱柱形电容器
本公司现有FML4460大量现货，欢迎新老客户洽谈购买。 点击这里下载FML系列样本
西班牙LIFASA其他相关产品可以在线浏览样本或者下载保存浏览。点此浏览西班牙lifasa品牌其他产品
原FMD系列产品已于2011年5月份起升级换代为FML系列，同一产品适用于不同电压等级，为客户提供更多便利；产品尺寸与原来相同，便于用户替换原使用产品，重量比原来产品有所下降；产品颜色由原来的蓝色改变为灰白色（RAL7035）。详细产品资料请参见下方介绍或来信来电咨询。
西班牙LIFASA公司自1949年起生产高品质电容等产品。产品包括：马达启动电容、高压电力电容器、照明电容器、电容器组、附接触器无功补偿电容、滤波阻抗电容、铝电解电容器、高频旁路电容器、高频耦合电容器、陶瓷电容器、调谐电容器、聚苯乙烯电容器、塑料薄膜电容器、吸收过滤器…
LIFASA电容器系适用于工频50Hz或60Hz、额定电压1000V及以下的交流电力系统中与负载并联，以提高系统的功率因数。 西班牙LIFASA电容器采用 自愈式金属化薄膜，大大增强了电容器元件的端面接合力和高耐压的要求，从而提高了电容器的抗涌流性能和KK性；减少了投入电容器瞬间对元件的电流冲击，从而有效延长电容器的使用寿命。
上海山合海融商贸有限公司代理销售西班牙LIFASA公司电容器类产品，主要包括以下部分型号：
FML4440（原FMD4030）、FML4460（原FMD4050）、FMLR4050、FMLR4030、MFB23050、FMLS4430、ELEFP40016AE、POLT44012、POLB44182SK、CPF4420、CPM4450、CAB14460、BATM0844175I、BATM080、BATLV180、BATLV360、BATLV400、BATLV800、BATLV1200、BATLV1600、INA、INR、INAS、INRS、FMLF、FMLFS、BATLVF400、BATLVF600、BATLVF800、BATLVF1000、BATLVF1200、BATLVFS400、BATLVFS600、BATLVFS800、BATLVFS1000、BATLVFS1200、HBF-T、TFA、HAF、HPF、SINAF、MCE ADV、MCE-FPlus、PFCL Elite、TCP、MC、CTF-CTB、MCA PLUS、MOTOR AND LIGHTING CAPACITORS等等。
产品特点：
1． 螺栓出线方式，BZ了接线的KK稳定，满足大容量、大电流的要求；
2． 安全KK的美式过压力防爆结构，内置式放电电阻，使得产品更安全，更KK；
3． 长寿命、多元件设计，增加散热面积，使电容器的温升更低，延长电容器的使用寿命；
4． 电容器元件用金属化薄膜采用 方阻设计，既有很高的自愈性能，又满足了高KK性的接触和高耐压的要求；
5． 安全有效的防护措施，免除对人体的伤害；
6． 方便KK的安装方式，提高了工作效率；
7． 优质圆柱形铝外壳，美观漂亮，更小的体积，使得单柜的容量更大。
公司介绍：
More than 60 years of history
International Capacitors S.A. is a consolidated company in both Spanish and international markets thanks to many years of experience and dedication to what it has been its product par excellence along its history: the capacitor for the electrical installation. With its commercial brand name LIFASA, present in the market for more than 60 years and a constant technical and technological evolution, it has succeeded in getting adapted continuously to the progress and market requirements nowadays.
LIFASA capacitors are present in the market since 1949. More than 50 % are exported to 70 countries in five continents. Capacitors are manufactured according to European and other International Standards. They have obtained large number of certificates and approvals. |
60多年的公司历史
International Capacitors S.A.（西班牙国际电容器公司）作为一家综合型公司，得益于多年的经验和奉献精神，凭借着公司发展历史中引以为豪的电气安装系统中的电容器产品，为西班牙国内和国考市场提供了大量的电容器产品。借助超过60年历史的商业品牌LIFASA和持续的科技发展，现在它已经成功地得到持续的增长和适应市场的需求。
|
Highest quality standards
International Capacitors S.A. has been from its beginnings a pioneering company in the promotion of the quality of its products. Since 1987, it maintains an Quality System periodically audited by international bodies.
|
高的质量标准
International Capacitors S.A.（西班牙国际电容器公司）早已不是一个依赖提升其产品质量的初创公司。
|
Comprehensive services
The company is commited to give the best service with maximum flexibility to meet customer requirements.
Economical and technical advices.
Support in installation and commissioning.
Permanent support during the whole life of our products.
Trainig on site and in factory.
International warranty.
Every person in the company is trained and motivated to participate actively in achieving this objective. |
QFW的服务
公司致力于以Z大的灵活性提供Z好的服务，以满足客户的要求。
经济和技术建议。
在安装和调试过程中提供支持。
在我们产品的整个生命过程中YJ性的支持。
现场和工厂培训。
GJ范围内的保修。
公司中的每一位员工都获得良好的培训并积极参与以实现这一目标。 |
产品简介及技术参数：
Self-healing capacitors with low losses metallized polypropylene dielectric without liquid impregnants. Mounted in rectangular sheet steel plate enclosure having discharge resistors connected to the terminals, which are protected by the cover.
These capacitors are especially suitable for the individual compensation of inductive loads and the construction of capacitor banks. |
低损耗的金属化聚丙烯电介质不含液体浸渍剂的自愈电容器。矩形板钢板外壳，内部的放电电阻连接到接线端，上面配有保护盖。
这些电容器特别适用于感应负载的单只补偿和电容器组。 |
Technical Characteristics
Rated Voltage ............ .230-1000V
Frequency ................ ..50Hz
Dielectric ............... . . .Polypropylene
Discharge resistors ...... Fitted
Dielectric losses ........ . .≤ 0.2 W/kvar
Total losses ............. . .≤ 0.4 W/kvar
Max. Overvoltage .........1.1 Un (8h/dia/day)
Max. Overcurrent .........1.3 In
Insulation level ........ .3/15 kV
Power tolerance ..........-5/+10 %
Climatic range ........... .-40/+55 oC
Connection ............... .M10
Protection degree ........
Colour .................. . ..RAL7035
Standard ................. ./
*Other power, voltages and frequencies on request. |
技术参数
电压范围 .................230-1000V
频率 .....................50Hz
介质 .....................聚丙烯
放电电阻 .................固定式
介电损耗 .................≤ 0.2 W/kvar
总损耗 ...................≤ 0.4 W/kvar
Z大过电压 ...............1.1 Un (8h/dia/day)
Z大过电流 ...............1.3 In
绝缘等级 ................3/15 kV
功率容错 .................-5/+10 %
温度范围 .................-40/+55 oC
连接件 ...................M10
防护等级 .................
颜色 .....................工业灰色
符合标准 ................./
*其他电力、电压、频率的电容器可以按要求定做。 |
产品图片及尺寸图：
型号及规格列表：
Part
number |
50 Hz |
Capacitance
(μF) |
H
(mm) |
Weight
(kg) |
Price
(�) |
| 230 V |
240 V |
260 V |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
| FML2305 |
5 |
12.6 |
5.4 |
13.1 |
6.4 |
14.2 |
3x100 |
270 |
2.8 |
319,73 |
| FML2307 |
7.5 |
18.8 |
8.2 |
19.6 |
9.6 |
21.3 |
3x150 |
270 |
2.8 |
352,80 |
| FML2310 |
10 |
25.1 |
10.9 |
26.2 |
12.8 |
28.4 |
3x201 |
270 |
3.5 |
385,88 |
| FML2312 |
12.5 |
31.4 |
13.6 |
32.7 |
16 |
35.5 |
3x251 |
270 |
3.5 |
420,00 |
| FML2315 |
15 |
37.7 |
16.3 |
39.3 |
19.2 |
42.6 |
3x301 |
270 |
3.5 |
452,03 |
| FML2320 |
20 |
50.2 |
21.8 |
52.4 |
25.6 |
56.8 |
3x401 |
270 |
4.2 |
617,40 |
| FML2325 |
25 |
62.8 |
27.2 |
65.5 |
31.9 |
70.9 |
3x501 |
270 |
5 |
782,78 |
| FML2330 |
30 |
75.3 |
32.7 |
78.6 |
38.3 |
85.1 |
3x602 |
270 |
5 |
848,93 |
| FML2335 |
35 |
87.9 |
38.1 |
91.7 |
44.7 |
99.3 |
3x702 |
460 |
6.8 |
964,69 |
| FML2340 |
40 |
100.4 |
43.6 |
104.8 |
51.1 |
113.5 |
3x802 |
460 |
7.5 |
1.102,50 |
| FML2350 |
50 |
125.5 |
54.4 |
131 |
63.9 |
141.9 |
3x1003 |
460 |
8.2 |
1.334,03 |
| FML2360 |
60 |
150.6 |
65.3 |
157.2 |
|
|
3x1203 |
460 |
9 |
1.543,50 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Part
number |
50 Hz |
Capacitance
(μF) |
H
(mm) |
Weight
(kg) |
Price
(�) |
| 440 V |
400 V |
415 V |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
| FML4412 |
12.5 |
16.4 |
10.3 |
14.9 |
11.1 |
15.5 |
3x69 |
270 |
2.8 |
286,65 |
| FML4415 |
15 |
19.7 |
12.4 |
17.9 |
13.3 |
18.6 |
3x82 |
270 |
2.8 |
341,78 |
| FML4420 |
20 |
26.2 |
16.5 |
23.9 |
17.8 |
24.8 |
3x110 |
270 |
3.5 |
396,90 |
| FML4425 |
25 |
32.8 |
20.7 |
29.8 |
22.2 |
30.9 |
3x137 |
270 |
3.5 |
452,03 |
| FML4430 |
30 |
39.4 |
24.8 |
35.8 |
26.7 |
37.1 |
3x164 |
270 |
3.5 |
485,10 |
| FML4440 |
40 |
52.5 |
33.1 |
47.7 |
35.6 |
49.5 |
3x219 |
270 |
4.2 |
595,35 |
| FML4445 |
45 |
59 |
37.2 |
53.7 |
40 |
55.7 |
3x247 |
270 |
4.2 |
633,94 |
| FML4450 |
50 |
65.6 |
41.3 |
59.6 |
44.5 |
61.9 |
3x274 |
270 |
5 |
672,53 |
| FML4460 |
60 |
78.7 |
49.6 |
71.6 |
53.4 |
74.3 |
3x329 |
270 |
5 |
771,75 |
| FML4475 |
75 |
98.4 |
62 |
89.5 |
66.7 |
92.8 |
3x411 |
460 |
6.8 |
882,00 |
| FML4480 |
80 |
105 |
66.1 |
95.4 |
71.2 |
99 |
3x438 |
460 |
7.5 |
981,23 |
| FML4490 |
90 |
118.1 |
74.4 |
107.4 |
80.1 |
111.4 |
3x493 |
460 |
7.5 |
1.025,33 |
| FML4499 |
100 |
131.2 |
82.6 |
119.3 |
89 |
123.8 |
3x548 |
460 |
8.2 |
1.157,63 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Part
number |
50 Hz |
Capacitance
(μF) |
H
(mm) |
Weight
(kg) |
Price
(�) |
| 460 V |
400 V |
440 V |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
| FML4610 |
10 |
12.6 |
7.6 |
10.9 |
9.1 |
12 |
3x50 |
270 |
2.8 |
275,63 |
| FML4615 |
15 |
18.8 |
11.3 |
16.4 |
13.7 |
18 |
3x75 |
270 |
3.5 |
363,83 |
| FML4620 |
20 |
25.1 |
15.1 |
21.8 |
18.3 |
24 |
3x100 |
270 |
3.5 |
418,95 |
| FML4625 |
25 |
31.4 |
18.9 |
27.3 |
22.9 |
30 |
3x125 |
270 |
4.2 |
507,15 |
| FML4630 |
30 |
37.7 |
22.7 |
32.7 |
27.4 |
36 |
3x150 |
270 |
4.2 |
529,20 |
| FML4640 |
40 |
50.2 |
30.2 |
43.7 |
36.6 |
48 |
3x201 |
270 |
5 |
639,45 |
| FML4650 |
50 |
62.8 |
37.8 |
54.6 |
45.7 |
60 |
3x251 |
460 |
6.8 |
738,68 |
| FML4660 |
60 |
75.3 |
45.4 |
65.5 |
54.9 |
72 |
3x301 |
460 |
7.5 |
848,93 |
| FML4675 |
75 |
94.1 |
56.7 |
81.9 |
68.6 |
90 |
3x376 |
460 |
9 |
959,18 |
| FML4680 |
80 |
100.4 |
60.5 |
87.3 |
73.2 |
96 |
3x401 |
460 |
9 |
1.069,43 |
| FML4699 |
100 |
125.5 |
75.6 |
109.1 |
91.5 |
120.1 |
3x501 |
550 |
10.9 |
1.256,85 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Part
number |
50 Hz |
Capacitance
(μF) |
H
(mm) |
Weight
(kg) |
Price
(�) |
| 525 V |
480 V |
550 V |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
| FML5210 |
10 |
11 |
8.4 |
105 |
11 |
11.52 |
3x38.5 |
270 |
2.8 |
292,16 |
| FML5215 |
15 |
16.5 |
12.5 |
158 |
16.5 |
17.28 |
3x57.7 |
270 |
3.5 |
385,88 |
| FML5220 |
20 |
22 |
16.7 |
20.11 |
22 |
234 |
3x77 |
270 |
3.5 |
474,08 |
| FML5225 |
25 |
27.5 |
20.9 |
25.14 |
27.4 |
28.8 |
3x96.2 |
270 |
4.2 |
573,30 |
| FML5230 |
30 |
33 |
25.1 |
30.16 |
32.9 |
34.56 |
3x115 |
270 |
4.2 |
661,50 |
| FML5240 |
40 |
44 |
33.4 |
40.22 |
43.9 |
468 |
3x154 |
270 |
5 |
826,88 |
| FML5250 |
50 |
55 |
41.8 |
50.27 |
54.9 |
57.6 |
3x192 |
460 |
6.8 |
1.003,28 |
| FML5260 |
60 |
66 |
50.2 |
60.33 |
65.9 |
69.12 |
3x231 |
460 |
7.5 |
1.179,68 |
| FML5275 |
75 |
82.5 |
62.7 |
75.41 |
82.3 |
86.41 |
3x289 |
460 |
9 |
1.389,15 |
| FML5280 |
80 |
88 |
66.9 |
80.44 |
87.8 |
92.17 |
3x308 |
460 |
9 |
1.598,63 |
| FML5290 |
90 |
99 |
75.2 |
90.49 |
98.8 |
103.69 |
3x346 |
550 |
10.2 |
1.819,13 |
| FML5299 |
100 |
110 |
83.6 |
100.55 |
109.8 |
115.21 |
3x385 |
550 |
10.9 |
1.990,77 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Part
number |
50 Hz |
Capacitance
(μF) |
H
(mm) |
Weight
(kg) |
Price
(�) |
| 690 V |
600 V |
725 V |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
| FML6910 |
10 |
8.4 |
7.6 |
7.3 |
11 |
8.8 |
3x66.9 |
270 |
2.8 |
297,68 |
| FML6915 |
15 |
12.6 |
11.3 |
10.9 |
16.6 |
13.2 |
3x100 |
270 |
3.5 |
319,73 |
| FML6920 |
20 |
16.7 |
15.1 |
14.6 |
22.1 |
17.6 |
3x134 |
270 |
3.5 |
485,10 |
| FML6925 |
25 |
20.9 |
18.9 |
18.2 |
27.6 |
22 |
3x167 |
270 |
3.5 |
584,33 |
| FML6930 |
30 |
25.1 |
22.7 |
21.8 |
33.1 |
26.4 |
3x201 |
270 |
4.2 |
661,50 |
| FML6940 |
40 |
33.5 |
30.2 |
29.1 |
44.2 |
35.2 |
3x267 |
270 |
5 |
837,90 |
| FML6950 |
50 |
41.8 |
37.8 |
36.4 |
55.2 |
44 |
3x334 |
270 |
5 |
1.003,28 |
| FML6960 |
60 |
50.2 |
45.4 |
43.7 |
66.2 |
52.8 |
3x401 |
460 |
6.8 |
1.190,70 |
| FML6975 |
75 |
62.8 |
56.7 |
54.6 |
82.8 |
65.9 |
3x501 |
460 |
7.5 |
1.267,88 |
| FML6980 |
80 |
66.9 |
60.5 |
58.2 |
88.3 |
70.3 |
3x535 |
460 |
8.2 |
1.433,25 |
| FML6999 |
100 |
83.7 |
75.6 |
72.8 |
110.4 |
87.9 |
3x669 |
460 |
9 |
1.466,33 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Part
number |
50 Hz |
Capacitance
(μF) |
H
(mm) |
Weight
(kg) |
Price
(�) |
| 1000 V |
900 V |
1100 V |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
Qn
(kvar) |
In
(A) |
| FML0010 |
10 |
5.8 |
8.1 |
5.2 |
12.1 |
6.4 |
3x31.8 |
270 |
3.5 |
304,50 |
| FML0015 |
15 |
8.7 |
12.2 |
7.8 |
18.2 |
9.5 |
3x47.7 |
270 |
5 |
367,50 |
| FML0020 |
20 |
11.5 |
16.2 |
10.4 |
24.2 |
12.7 |
3x63.7 |
270 |
5 |
498,75 |
| FML0025 |
25 |
14.4 |
20.3 |
13 |
30.3 |
15.9 |
3x79.6 |
460 |
7.5 |
577,50 |
| FML0030 |
30 |
17.3 |
24.3 |
15.6 |
36.3 |
19.1 |
3x95.5 |
460 |
7.5 |
672,00 |
| FML0035 |
35 |
20.2 |
28.4 |
18.2 |
42.4 |
22.2 |
3x111 |
460 |
9 |
777,00 |
| FML0040 |
40 |
23.1 |
32.4 |
20.8 |
48.4 |
25.4 |
3x127 |
460 |
9 |
861,00 |
| FML0050 |
50 |
28.9 |
40.5 |
26 |
60.5 |
31.8 |
3x159 |
460 |
9 |
1.023,75 |
| FML0060 |
60 |
34.6 |
48.6 |
31.2 |
72.6 |
38.1 |
3x191 |
550 |
10.9 |
1.202,25 |
| FML0065 |
65 |
37.5 |
52.7 |
33.8 |
78.7 |
41.3 |
3x207 |
550 |
10.9 |
1.307,25 |
| FML0070 |
70 |
40.4 |
56.7 |
36.4 |
84.7 |
44.5 |
3x223 |
650 |
13 |
1.412,25 |
| FML0075 |
75 |
43.3 |
60.8 |
39 |
90.8 |
47.6 |
3x239 |
650 |
13 |
1.517,25 |
Other power, voltages and frequencies on request. |
