TEL-AL11-1 ~ TEL-AL11-5   Accessories
Test Leads
TEL-AL11-1 ~ TEL-AL11-5
FEATURES

 Wire : PVC UL 1803/18AWG, Length : 1100 +/- 30mm, Out diameter : 4.0 mm, Temperature tolenrance range : -45 degree ~ 105 degree, Braid copper wires : 170/0.08mm
 Terminal 105 degree angle 4mm brass banana plug (nickel plated) with caged and insulated Sheathing to avoid the brass oxidation.
 Rating : CAT III 1000V 15A (170/0.08) / CAT IV 1000V 15A (200/0.08)
 Patented connector at test lead and terminal
 Test leads for meters and testers are highly susceptible to poor contact and damage.
 Our patented screw end has completely offset the bending oppression, which makes it highly durable and long lasting.
