REGULATOR NEUTRAL DETECTOR
• The RND insures that the operator has the regulator in its neutral
position prior to disconnecting the regulator from the circuit
• Use of the RND eliminates high or low voltages caused by cycling
the regulator to the upper or lower limits and then counting steps back
to neutral
• Works with step type and induction type regulators
• 0 - 2000 volt range is shown in one volt increments
• Works with all regulators up to and including 34.5KV systems
• No range selector is required
• Digital display with 1/2” tall LCD digits for easy viewing
• Lighted meter for use at night can be switched on by the operator
• 9 volt battery included
• Low battery indicator
• The RND verifies the step indicator has not slipped one step
• A female universal spline allows unit to be attached to all universal
hot sticks
• Contact electrodes are knurled to aid in contact with conductors
| CAT NO |
DESCRIPTION |
LBS |
| 6709-1 |
REGULATOR NEUTRAL DETECTOR, COMPLETE
WITH CASE, BATTERY, AND INSTRUCTIONS |
4.6 |
| A30113 |
REPLACEMENT CASE |
2.4 |
UNDERGROUND HIGH VOLTAGE METER
• Instrument for underground potential testing
• Can measure voltage potential up to and including 20KV line
to ground
• Accessories - Loadbreak bushing adapters for 15KV, 25KV,
and 35KV underground and primary systems.
• Digital display reads directly in kilovolts with a 1/2” high, 3
digit display. Readout is given to the nearest 100 volts. Has
a lighted background that can be turned on by the operator as
required.
• Low battery indicator
• Includes 9 volt battery
• The coiled, self-retracting cable is 16” retracted and 10’ when
fully extended
• Also included is the carrying case that will also hold a pair of
bushing adapters
• Attaches to all universal hot sticks
| CAT NO |
DESCRIPTION |
LBS |
| 6704 |
UNDERGROUND HIGH VOLTAGE METER WITH CARRYING CASE, BATTERY AND
INSTRUCTIONS |
4.8 |
| 6702-1 |
15/25KV LOADBREAK BUSHING ADAPTER
(1 EACH) |
0.6 |
| 6702-3 |
35KV LOADBREAK BUSHING ADAPTER (1
EACH) |
0.8 |
| A30390 |
REPLACEMENT STORAGE CASE |
2.1 |
