WIRELESS PHASING METER
• The Phase-Tell III is a battery powered, two-piece wireless phasing tool.
• Used to determine phase relationships on three phase power systems, overhead and URD applications.
When contact is made with line voltage or elbow test points, the Phase-Tell III units compare transmit-
ted data and then display the results via Red or Green LED lights and differentiated audible signals.
Flashing green lights indicate In-Phase. Flashing red lights indicate Out-of-Phase.
• Wireless units communicate up to three hundred feet apart.
• Both units are identical, no need to identify transmitter or receiver.
• Voltage range from URD test points to 500KV.
• Both units confirm the same phase readings.
• Rugged extruded aluminum enclosure.
• Each unit operates on two “AA” batteries, included.
• FCC Compliant.
• Automatic test cycle when placed in the “On” position.
• Auto Shut-Off.
• Includes carrying case and instructions.
• URD bushing adapters and case available.
| CAT NO |
DESCRIPTION |
LBS |
| 6722 |
PHASE-TELL III, WIRELESS PHASING
METER |
6.5 |
| 266 |
URD BUSHING WELL ADAPTER |
1.5 |
| 01-266 |
PADDED CASE FOR BUSHING ADAPTERS |
1.5 |
